PrestiVac

Powder Coating Vacuum Solutions

Grounded. Contained. Color-change ready.

Powder coating charges combustible polymer powder on purpose — which makes ungrounded cleanup equipment uniquely wrong for the environment. PrestiVac recovery systems close the loop the booth doesn't: fugitive overspray, color changeover and hopper cleanout, with grounding verified end to end.

Get a QuoteFind Your System
Vacuum nozzle recovering fine white powder from a shop floor

  • Explosion-Safe Design

    Engineered to NFPA 33 / 660 practice

  • HEPA Filtration

    Fines retained; next color protected

  • Static Control

    Grounded recovery in an electrostatic process

  • Faster Color Change

    Single-pass cleanout on the critical path

Overview

The spray booth reclaims overspray by design — that's the process working. The housekeeping gap is everything the booth's own recovery doesn't own: fugitive powder that settles beyond capture, hopper and feed-area spills, rack and fixture buildup, and the color-change cleanout that sits directly on the production schedule. Coating powders are combustible polymer dusts, the environment is deliberately electrostatic, and the collected material is a waste stream that must never contaminate the reclaim stream.

  • Color Changeover

    Booth cleanout on the critical path

  • Booth & Hopper Areas

    Feed spills & residual powder

  • Fugitive Overspray

    Beyond the booth's capture

  • Racks & Fixtures

    Hanger and conveyor buildup

Challenges in powder coating

  • Coating powders are combustible polymer dusts — NFPA 33 spray-application territory, inside NFPA 652/660's DHA obligation
  • The process is deliberately electrostatic: charge is everywhere, and ungrounded cleanup gear adds risk exactly where it concentrates
  • Color-change cleanout sits on the production critical path — housekeeping speed is throughput
  • Fugitive powder settles beyond booth capture, on structure and equipment
  • Reclaim purity: floor-collected and fugitive powder is waste, and mixing streams contaminates expensive reclaim
  • Exposure considerations vary by chemistry — TGIC-bearing powders carry stricter handling

Why engineered vacuum recovery?

  • Explosion-proof construction for combustible polymer dust
  • Grounded, bonded path — the non-negotiable in an electrostatic process
  • Single-pass cleanout shortens color change instead of stretching it
  • HEPA-retained exhaust keeps fines out of booth air and the next color
  • Stream separation protects reclaim purity by rule, not vigilance
  • Supports compliance with NFPA 33 / 660 and OSHA housekeeping

Solution benefits

  • Better Safety

    Grounded explosion-proof recovery in a process that charges powder by design.

  • Higher Productivity

    Color change becomes a plannable single-pass method on the schedule.

  • Cost Savings

    Stream separation protects expensive reclaim powder from contamination.

  • Cleaner Workplace

    HEPA-retained fines stay out of booth air and the next color.

Typical system setup

  1. 01

    Booth / color-change point

    Residual and fugitive powder at the source

  2. 02

    Grounded tool kit

    Stainless wands and crevice tools, non-sparking

  3. 03

    EX vacuum unit

    Explosion-proof; grounding verified before use

  4. 04

    Multi-stage + HEPA

    Powder load staged; fines retained at 99.99%

  5. 05

    Sealed waste container

    Kept strictly separate from the reclaim stream

Collected floor and fugitive powder is a waste stream — reclaim purity lives in the booth's own recovery system, and keeping the two separate is the specification.

Powder Coating FAQ

The booth already recovers overspray — what's left for a vacuum?

Everything outside the booth's capture: fugitive powder on structure and equipment, hopper and feed spills, rack buildup, and the color-change cleanout itself. The booth is a process recovery system, not a housekeeping program.

Why is grounding emphasized so heavily here?

Because the process charges powder electrostatically on purpose — static is guaranteed, not incidental. Recovery equipment must be part of the grounded system, verified before use; an ungrounded vacuum is an isolated conductor in a charged space.

Can vacuum-collected powder be fed back to reclaim?

No — floor-collected and fugitive powder is contaminated by definition and is handled as waste in sealed, segregated containers. Reclaim purity lives in the booth's own loop; the streams never mix.

Does cured coating create a dust hazard?

The fused film on finished parts is inert — the hazard is the uncured powder. That's why the program targets booth perimeters, hoppers, changeovers and fugitive settlement rather than finished work.

Talk to the manufacturer

Get the right explosion proof vacuum for your application.

Tell us what you need to vacuum and where. Our technical team will recommend the PrestiVac model best suited to your material, your classification and how hard you will work it — and because we build every unit ourselves, we can modify it to fit.

Get a Quote
  • Legally certified explosion proof
  • Solid stainless steel construction
  • Industry-best 3-year warranty
  • Designed & manufactured in the USA
  • 200+ vacuum versions
